Trapezoidal panel design is mechanically snapped and works well for low-slope industrial applications and high performance, pre-engineered metal buildings
Substrate Offering:
22 Gauge Steel 24 Gauge Steel
Panel Features:
Factory Applied Sealant Snap-Fit Panel
Maximum Panel Length: 47′
Minimum Panel Length: 6′
Wind uplift | UL90 | #93, 210A |
---|---|---|
ASTM E1592 | Results vary depending on Gauge and Thickness | |
Air infiltration | ASTM E283 | .006 @ 20 psf |
ASTM E1680 | 0.00 @ 20 psf | |
Water penetration | ASTM E331 | No water @ 20 psf |
Water penetration | ASTM E1646 | No water @ 20 psf |
Minimum Roof Slope | 1/2: 12 | |
Available Widths | 24” | |
Standard Lengths | 6’ to 47’ |
